Merlin 13-Liemke Thermal Vision Monocular

€2,060.00
Tax included
Thermal Vision Monocular Merlin 13-Liemke
Quantity
En stock

  • Paiement 100% sécurisé par la Caisse d'Epargne ou Payplug Paiement 100% sécurisé par la Caisse d'Epargne ou Payplug
  • Livraison en point relais offerte à partir de 99€ Livraison en point relais offerte à partir de 99€
  • Satisfait ou remboursé ! Satisfait ou remboursé !

Merlin 13 Thermal Vision Monocular-Liemke

The Merlin 13 is equipped with a new 12 µm VOx ceramic detector and an ultra-compact design. With a weight of less than 150 g and unbeatable ease of use.

Technical Specifications

  • Objective diameter (mm): 13
  • Fixed focus
  • Sensor material: VOx Ceramic
  • Sensor resolution (pixels): 256x192
  • Pixel pitch: 12 µm
  • Frame rate: 25 Hz
  • NETD: <50 mK
  • Display resolution (pixels): HD 1,024x768 OLED
  • Field of view: 13.5x10°
  • Field of view width at 100 m in m: 24
  • Battery: 1x CR123
  • Duration: 3.5 hours
  • Protection class: IP67
  • Pixel FOV (mRad): 0.92
  • Weight: 130g
  • Range (m): 650m



Delivery Contents

  • Merlin 13
  • Adapter ring for use with clamp adapter
  • Instructions

Product Details

LIMERLIN13

Data sheet

Type d'optique
Lunette de tir
